Specifications

Dual Card Slots

Camcorder Type

HD Flash Memory Camcorder

Recording Hours

AVCHD

Memory capacity	PAL:50P	24Mbps	17Mbps	5Mbps
8GB	35mins	40mins.	1hr.	3hrs.
16GB	1hr. 15 mins	1hr. 25mins.	2hrs. 5mins.	6hrs. 5mins.
32GB	2hrs. 30mins	2hrs. 55mins.	4hrs. 10mins.	12hrs. 15mins.
64GB	5hrs. 5mins	5hrs. 55mins.	8hrs. 20mins.	24hrs. 30mins.

MP4

Memory capacity	35Mbps	24Mbps	17Mbps	4Mbps	3Mbps
8GB	30mins	40mins.	1hr.	4hr. 20mins.	5hr. 40mins.
16GB	1hr.	1hr. 25mins.	2hrs. 5mins.	8hrs. 40mins.	11hrs. 25mins.
32GB	2hrs.	2hrs. 55mins.	4hrs. 10mins.	17hrs. 20mins.	22hrs. 55mins.
64GB	4hrs.	5hrs. 55mins.	8hrs. 20mins.	34hrs. 45mins.	45hrs. 55mins.

AVCHD & MP4 recording: SDHC Class 4 or higher-speed memory cards
50P recording: SDHC Class 6 or higher-speed memory cards

Monitor

3.5-inch widescreen OLED touch panel colour, approx. 1.23million dots with dimmer setting

Electronic Viewfinder (EVF)

0.24-inch, approx. 1.56million dot colour LCD monitor

Image Sensor

1/2.84-inch HD CMOS Pro sensor, approx. 3.09 megapixels, RGB primary colour filter

Microphone

Stereo Condenser Microphone

Lens

20x optical zoom

Digital Zoom

400x (Movie mode only)

Lens Configuration

12 elements in 10 groups, 2 Aspherical lens used

Filter Diameter

58mm P0.75

Image Stabilizer

Intelligent IS

AF System

High-speed AF (Instant AF), Medium AF, Face Priority AF, Face-Only AF, Touch Focus, Manual focus Ring

Video Recording Specifications

Video Recording Standards

AVCHD (AC-3/H.264 standard):

HD Recording only 1920 x 1080 / 1440 x 1080 recording supported

MP4 (AAC/H.264 standard):

HD Recording only 1920 x 1080 / 1280 x 720 / 640 x 360 recording supported

Effective Pixels

2136 x 1362

Audio Compression

AVCHD:

Dolby Digital 2ch (AC-3 2ch)

MP4:

MPEG-2 AAC-LC (2ch)

Shooting Modes

Smart Auto, P, Tv, Av, M, Cinema, Portrait, Sports, Night, Low light, Snow, Beach, Sunset, Spotlight, Fireworks, Infrared

Shutter Speed Range

Tv mode:

1/6 - 1/2000

P mode:

1/12.5 - 1/500

Low light mode:

1/2 - 1/500

Minimum Illumination

Approx. 0.1lx (low light mode)

Cinema Style

Cinema-look filters

Image Effects

Brightness, Contrast, Sharpness, Colour Depth

Relay Recording

Supported

Double Slot Recording

Supported

Recording Check

Supported

Wi-Fi Specifications

Ratings

IEEE 802.11 b/g/n/a (2.4GHz / 5GHz* band), Wi-Fi authentication obtained. IEEE 802.11n recommended
* some countries do not support 5GHz band

Wi-Fi Settings Methods

WPS (Wi-Fi Protected setup) (Push button system, PIN code system)
Manual setting
Search for access points

Connection Modes

Infrastructure
Easy AP mode

Authentication Systems

Open or shared key
WPA-PSK / WPA2-PSK

Encryption Systems

WEP-64 / WEP-128
TKIP / AES

Wi-Fi Connection Service Camera Mode

Wi-Fi remote - enables remote access of camcorder to be performed from web browser

Wi-Fi Connection Service Playback Mode

Movie Uploader - Save and upload videos to YouTube or facebook via iOS device
Playback via browser - Camcorder contents can be played or downloaded via internet browser
Media Server - Camcorder videos can be viewed wirelessly via DLNA devices
FTP file transfer - enables data to be transferred to a FTP server
Web service - Function for transferring image/video to a Canon image Gateway server (not available in certain countries)

Still Image Recording Specifications

Still Image Recording

SD / SDHC / SDXC memory card

Still Image Compression

Exif Ver. 2.3 specifications satisfied

Compression method:

JPEG

Recording Pixels

In movie Rec Pause and Photo Mode:

1920 x 1080

Shooting Modes

Smart Auto, M, P, Tv, Av, Portrait, Sports, Snow, Beach, Sunset, Night, Low light, Spotlight, fireworks, Infrared

Easy Operations Features

Zoom

Zoom lever

Navigation

Touch based OLED panel

Extended Control

Remote Control

Battery

Rechargeable Intelligent lithium battery BP820
(Optional battery BP828 / 975 / 955 / 925)

Input / Output Terminals

Video Out

Mini HDMI, AV Cable

Analog Output

Yes

Microphone Terminal

Yes

HDMI-Out

Supported

Physical Dimensions & Power

Power Supply (Rated)

7.4 V DC (battery pack), 8.4 V DC (DC in)

Operating Temperature

0 - 40°C 85% (relative humidity)
-5 - 45°C 60% (relative humidity)

Dimensions

Approx. 109 x 84 x 182mm (4.3 x 3.3 x 7.2in.)

Weight (Main Unit)

Approx. 765g (1.7lb)
