PARTS MANUALrev 28 May 2008
T5-0 TREADMILL | T50-0XXX-01 |
CONTENTS |
Miscellaneous .......................................................................................................... | 3 |
Extrusions and Rear End Caps ....................................................................................... | 4 |
Console and Related Components .................................................................................. | 5 |
Belt, Deck, and Rear Roller.......................................................................................... | 6 |
Uprights, Handrails, and Cupholders............................................................................... | 7 |
Ergo Bar................................................................................................................. | 8 |
Motor Cover, Front End Cap, and Leg Levelers................................................................... | 9 |
Lift Frame and Lift Motor ........................................................................................... | 10 |
Motor Controller Assembly.......................................................................................... | 11 |
Drive Motor Assembly................................................................................................ | 12 |
Front Roller Assembly ............................................................................................... | 13 |
Block Diagram - Domestic........................................................................................... | 14 |
Block Diagram - International ...................................................................................... | 15 |
2
T5-0 TREADMILL | T50-0XXX-01 |
Miscellaneous |
Description | Part No. |
Hardware Bag T5-0-T7.0 | AK59-00090-0000 |
Document Kit T5-0/T5.5/T7.0 Eng | AK59-00110-0000 |
Document Kit T5-0/T5.5/T7.0 Ger | AK59-00110-0002 |
Assembly, Document Kit T5-0 Eng | AK59-00110-0000 |
Assembly, Document Kit T5-0 Ger | AK59-00110-0002 |
Transmitter, Polar HR | 8254701 |
Strap, Heart Rate LF | 6844301 |
Wrench, M6, Hex Long Arm | 3255701 |
3
T5-0 TREADMILL | T50-0XXX-01 |
Extrusions and Rear End Caps |
Extrusion, Right
AK59-00088-0000
Extrusion, Left
AK59-00089-0000
Lower Extrusion (2) End Cap, Left 0K59-01174-0000 0K59-01177-0000
Rear Roller Guard, Left | |
0K59-01209-0000 | |
Rear Tensioning Bolt | Rear Roller Guard, Right |
0K59-01208-0000 | |
3253907 | |
Flat Washer | Extrusion Mounting Clip |
3114409 | |
0K59-01254-0000 | |
Trx Pan Screws (20) | |
3206601 |
End Cap, Right | ||
Screw | 0K59-01176-0000 | |
0017-00101-1621 | ||
Grommets | Extrusion Mounting Brackets (8) | |
0017-00042-0326 | ||
7074401 | ||
Trx Pan Screws (16) | ||
3206601 | ||
4
T5-0 TREADMILL | T50-0XXX-01 |
Console and Related Components |
Attaching the Console Assembly to the Lower Cross Cover | |
Cross Cover | Screw (4) |
(see page 7) | 3254602 |
Console Assembly | |
Overlay/Bezel Assembly (see chart below)
Programmed Console Board
A084-92313-A001
Console Case, Back 0K59-01202-0000
Life Fitness Logo 0K59-01282-0000
Language | Part Nos. | ||
Console | Overlay/Bezel | ||
Assembly | Assembly | ||
ENG/ENG | AK59-00061-0000 | AK59-00114-0000 | |
GER/MET | AK59-00061-0002 | AK59-00115-0000 | |
5
T5-0 TREADMILL | T50-0XXX-01 |
Belt, Deck, and Rear Roller |
Walking Belt 0K59-01133-0001
Rear Roller | Deck (with |
0K59-01169-0000 | |
belt removed) | |
0K59-01172-0000 | |
TecsPac Spring Blk (8) | |
6821901 | |
TecsPak Screw (8) | |
3234804 | Deck Screws (4) |
TecsPak Washer (8) | 3206301 |
3114412 | Tinnerman Clip (4) |
3206201 |
6
T5-0 TREADMILL | T50-0XXX-01 |
Uprights, Handrails, and Cup Holders |
Accessory Holder, Blue | Insert Cup, Blue | |
0K59-01244-0000 | Screws (2) | 0K59-012405-0000 |
Outer Cupholder Cover | ||
3207501 | ||
0K59-01200-0000 | ||
Cross Cover Assembly | ||
AK59-00087-0000 |
Inner Cupholder Cover | |
0K59-01199 | |
Bottom Cross Cover | |
0K59-01203-0000 | |
Screws (2) | |
Bridge Assembly | 3255504 |
AK59-00060-0000 | |
Ergo Bar | Handlebar Grip |
(see page 8) | |
0K59-01135-0000 |
Upright End Cap 0K59-01136-0000
Handlebar End Cap 0K59-01134-0000
Upright Bolt (4) | |
3254902 | |
not shown: | |
Foam Strip | |
7985801 | |
these hold the main cable | Lock Washer (4) |
to the bridge assembly: | |
3239503 | |
Plastic Tension Clips (2) | |
3255601 | |
Phil Pan Screws (2) | |
3226003 |
Felt Bumper 3255401
Upright Assemblies
Left
AK59-00055-0000
Right
AK59-00054-0000
Upright
Frame
T5-0 TREADMILL | T50-0XXX-01 |
Ergo Bar |
Top Ergo Bar Cover 0K59-01205-0000 Nylon Screw Grommet 0017-00042-1147
Ergo Handlebar Grip, Left 0K59-01302-0000
T50 User Pod Assembly
AK59-00069-0000
Disk Magnet - Metal Disk 6855301
Bottom Ergo Bar Cover 0K59-01204-0000
Safety Key Assembly
AK59-00062-0000
Adhesive Tape 0K39-01044-0000
Screws (4) 0017-00101-1621
Ergo Bar Weldment 0K59-01226-0000
Ergo Handlebar Grip, Right 0K59-01239-0000
Screws (4) 3226003
T5-0 TREADMILL | T50-0XXX-01 |
Motor Cover, Front End Cap, and Leg Levelers |
Motor Cover Assembly AK59-00096-0000
10 inch Logo Label
0K59-01284-0000
Motor Cover Clips (2) 0K59-01317-0000
Screws (2) 3223501
Screws (2) 0017-00101-1621
Lower Front Cover 0K59-01173-0000
Life Fitness T5.0
Leveler Tube Cap End 0K59-01175-0000
Screws (3) 0017-00101-1621
Grommets (3) 0017-00042-0326
Jam Nut | Leg Leveler Assembly |
AK59-00119-0000 | |
3225802 |
Leg Leveler 3231701
9
T5-0 TREADMILL | T50-0XXX-01 |
Lift Frame and Lift Motor |
Flat Ny Washers (2) 3227202
Low Ht Nylock Nut Hex Bolt 3102807 3223304
Linear Actuator 115/60
0K59-01064-0000 230/50
0K59-01259-0000
Lift Frame Assembly
0K59-01158-0001
External E-rings (2) 3221705
Actuator Lift Frame Pins (2) 0K59-01187-0000
Endcaps (4) 6836601
Wheels (2)
0K59-01164-0000 Pushnut
3205101
Clevis Pins, 3/8 x 20 (2) 3256001
Lift Frame Pivot Sleeves (2) 0K59-01298-0000
Cotter Hairpins (2) 3257101
T5-0 TREADMILL | T50-0XXX-01 |
Motor Controller Assembly |
Motor Controller Kit:
Domestic: AK59-00112-0000
International: AK59-00113-0000
Screws (2) 3208601
11
T5-0 TREADMILL | T50-0XXX-01 |
Drive Motor Assembly |
Drive Belt Tensioning Bolt 3205401
Washer | Line Cord, Domestic |
3102500 | 7420601 |
Drive Motor Assembly | ||
Domestic, 120 v. | Home Switch | |
7934401 | ||
International, 230 v. | 3204701 | |
Drive Motor Mounting Nuts | 7934601 | Retaining Clip |
3205801 | 6872701 |
Poly-V Belt | Bushing, Strain Relief |
3206901 | |
3259501 |
12
T5-0 TREADMILL | T50-0XXX-01 |
Front Roller Assembly |
Front Roller Assembly w/Pulley
AK59-00063-0000
Parts For Life Fitness T5
front
T5 Pulley Guard | Flat Washer |
0K59-01241-0000 | |
Plastic Grommets (2) | 3114409 |
0017-00042-0326 | |
Phil Pan Screws (2) | HXS Soc Bolt |
0017-00101-1621 | |
3253913 |
Tensioning Bolt
3253907
Washer
Life Fitness T5 Treadmill Manual
3114409
13
CBL-ASSY: AZ TO CONSOLE T5.0 | –DiagramBlock | TREADMILLT50- |
AK59-00078-0000 | ||
CONSOLE PCB | ||
CONSOLE | 92313 | |
KEYPAD | ||
ACTIVITY ZONE | ||
KEYPAD | Low | |
CBL-ASSY: HR REC TO | ||
CONSOLE | ||
AK59-00077-0000 | E H BLK | Voltage |
CBL-ASSY: POLAR | ||
PCB W/HEADER | ||
AK39-00064-0000 | ||
D T | ||
VCC (5V) | R W | CBL-ASSY: MC TO |
POLAR | ||
GND | ||
CONSOLE | ||
AK59-00076-0000 |
Life Fitness T5-5 Manual
CBL-ASSY: POWER CONTROL | |||
CBL-ASSY: HOME SWITCH | AK59-00083-0000 | ||
ON/OFF SWITCH | |||
AK59-00084-0000 | |||
3204801 | |||
TRANSFORMER | |||
INDUCTOR: 3MH; 120V | |||
111E-00001-0044 | |||
T50-0000-01 T5-0.ENG/ENG.120/60.DOM | |||
XFRMR: POWER; 115V/60HZ | O | PART # | DESCRIPTION |
PTO SENSOR ASSY | 7420601 | LINE CORD | |
0017-00003-1011 | |||
7059001 | AK59-00083-0000CBL-ASSY: POWER CONTROL | ||
01-0XXX-T50 | |||
CBL-ASSY: AZ TO CONSOLE T5.0 | –DiagramBlock | TREADMILLT50- | ||||
AK59-00078-0000 | ||||||
ACTIVITY ZONE | ||||||
KEYPAD | ||||||
CBL-ASSY: HR REC | High | |||||
TO CONSOLE | ||||||
AK59-00077-0000 | Voltage | |||||
CBL-ASSY: POLAR | ||||||
PCB W/HEADER | ||||||
AK39-00064-0000 | T50-0101-01 | T50-0102-01 | T50-0104-01 | T50-0201-01 | ||
D T | T5-0.ENG/MET. | T5-0.ENG/MET. | T5-0.ENG/MET. T5-0.GER/MET. | |||
E H BLK | ||||||
VCC (5V) | R W | 230/50.CONT | 230/50.UK | 240.AUST | 230/50.CONT | |
POLAR | CBL-ASSY: MC TO | |||||
GND | LINE CORD, CONT | 7420801 | 7420801 | |||
CONSOLE | ||||||
LINE CORD, UK | 7420901 | |||||
AK59-00076-0000 | ||||||
LINECORD, AUSTRALIA | 7802901 | |||||
CBL-ASSY: HOME SWITCH | CBL-ASSY: FILTER- | FILTER, LINE 10A | ||||
AK59-00084-0000 | ||||||
15 | TO-PCB | 3226101 | ON/OFF SWITCH | |||
TRANSFORMER | AK59-00102-0000 | 3204801 | ||||
INDUCTOR: | ||||||
15MH; 230V | ||||||
111E-00001-0042 | ||||||
CBL-ASSY: FILTER- | CBL-ASSY: FILTER POWER | |||||
XFRMR: POWER; 230V | AK59-00101-0000 | |||||
TO-PFC | ||||||
50HZ 'RAMSEY' N/D | OPTO SENSOR ASSY | AK59-00103-0000 | ||||
0017-00003-1010 | 7059001 | |||||
01-0XXX-T50 | ||||||
